Saturday, 22 April 2017

5 BEDROOM BUNGALOW WITH GARAGE

5 Bedroom bungalow with garage

                           This particular plan is the type for somebody that love big house with more than four bedroom that is also affordable.
www.latesthouseplan.blogspot.com

www.latesthouseplan.blogspot.com

  STAT

  • Bedroom: five bedroom
  • bathroom: five
  • Living area: a living area
  • Dinning : single
  • Foyer: one
  • Garage: one
  • Bonus room :none
  • Out door living : one porch and a balcony
  • Ceiling height :  9',8'
  • Width x depth : 54' 6"x 56' 3".
download links below:
click here 1
 click here 2
For more inquiry you can ring us on 07058946178

Friday, 19 August 2016

Three,Two and one bedroom Plan

  Three, two and one bedroom bungalow

            This particular plan will leave your mouth open as i give you simple plan that is also complex, i mean the one your money can afford.
             This particular plan has an apartment of three bedroom, a room self-contain and also two bedroom bungalow attached together. You just have to sit down and follow me as i analyze it.


           Three bedroom bungalow:

On this plan it has three bedroom, a foyer,dinning room,kitchen e.t.c


latesthouseplan.blogspot.com

 A room self-contain:

On this self-contain, it has one parlour, one bedroom, kitchen and a single toilet
latesthouseplan.blogspot.com

 Two bedroom bungalow:

On this plan we have two room, a single living area, a kitchen, dinning, toilets store e.t.c
latesthouseplan.blogspot.com

STAT

  • Bedroom: six bedroom
  • bathroom: six (three private and three general)
  • Living area: two and halve
  • Dinning : two casual
  • Foyer: one
  • Garage: none
  • Bonus room :none
  • Out door living : three verandah and two balcony
  • Ceiling height :  9',8'
  • Width x depth : 54' 6"x 96' 3".
download links below:
click here 1
 click here 2
For more inquiry you can ring us on 07058946178

Saturday, 13 August 2016

Three bedroom en suite

               Three bedroom en suite

   En suite room according to most of dictionary mean a room that is big and has its own toilet and every other necessary quality. This particular house plan has every quality that make it to be called
 or named as en suit.
                This three bedroom house plan is not a complex and can not also be said to be a simple one.It has a simple roof that match the colour of simple brick used for the construction as you  can see below
www.latesthouseplan.blogspot.com

        and also
www.latesthouseplan.blogspot.com

About the plan

                     It has three bedroom,four toilet, a foyer,a laundry, inverter house kitchen, dinning hall, store, living room, a porch and balcony.


STAT

  • Bedroom: Three bedroom
  • bathroom: Three private and one general toilet
  • Living area: single Main living
  • Dinning : casual
  • Foyer: none
  • Garage: none
  • Bonus room :inverter house and laundry
  • Out door living : porch and balcony
  • Ceiling height :  9'
  • Width x depth : 32' 3"x 63' 6".
download links below
            ensuit 1
            ensuit 2
credit:07058946178

Monday, 16 May 2016

Three bedroom classic

Three Bedroom Classic

      A classic according to encarta dictionary mean something that is fashionable and elegant, usually because of simplicity and restraint in style. This is the reason why you have this plan tag with the word classic.
       This three bedroom classic is not complex but simple and elegant because of its roofing style and it shape and it is a type of plan you can consider if you are are looking for something fashionable.
www.latesthouseplan.blogspot.com
              It has three bedroom, three toilet (two private and one general), a foyer, kitchen, dinning hall, store, living room, a verandah and balcony.

STAT

  • Bedroom: Three bedroom
  • bathroom: two private and one general toilet
  • Living area: single Main living
  • Dinning : casual
  • Foyer: one
  • Garage: none
  • Bonus room :none
  • Out door living : verandah and balcony
  • Ceiling height :  9'
  • Width x depth : 47'x 44'

Foundation details

  1. Concrete
    • Cement :35 bags of cement
    • Sharp sand : 140 head pan of sharp sand
    • Gravel : 280 head pan of gravel

  2. Block  :
  • Exterior :458 units of block
  • Interior : 500  units of block

Level break down

  •  Exterior wall : 1119 units of block
  • Interior wall : 1396 units of block

Roof details

  • Ridge cap : 152''
  • 4x8' roof sheet : 76 counts
  • Down spout : 12
  •  1"x 8" Gable fascial : 63'
  •  1"x 8" Eaves fascial  : 176'
Note that these estimate are  70% accurate.
For more detail about roofing terminology you can check my our my facebook page
Hope you have a nice time here ?
download link for this plan is as below
and
for comment,criticism or suggestion:  you can comment below or mail me on 247drawing@gmail.com





Thursday, 5 May 2016

FOUR BEDROOM BUNGALOW

    FOUR BEDROOM BUNGALOW

               Four bedroom  house plan from history seems to be the most commonest preferred house plan after three bedroom bungalow. Some people may decide to have two room down and two room up,three room down and one room up or one room down and three room up (duplex) , while some prefer to build all on a ground level (bungalow) which help to reduce cost.
             The term originated in India, deriving from the Gujarati બંગલો baṅgalo, meaning "Bengali" and used elliptically for a "house in the Bengal style".This Asian architectural form and design originated in the countryside of Bengal region in South Asia. Such houses were traditionally small, only one storey and detached, and had a wide verandah
               This particular plan is a four bedroom bungalow plan with dinning, Main living,a store, verandah,balcony, kitchen and three toilet (water closet and shower).

www.latesthouseplan.blogspot.com
                                                          orthogonal view
www.latesthouseplan.blogspot.com

         STAT
  • Bedroom: four bedroom
  • bathroom: two private and one general toilet
  • Living area: single Main living
  • Dinning : casual
  • Garage: none
  • Bonus room :none
  • Out door living : verandah and balcony
  • Ceiling height :  9'
  • Width x depth : 33' x 45'- 3"

Foundation details

  1. Concrete
    • Cement :33 bags of cement
    • Sharp sand : 132 head pan of sharp sand
    • Gravel : 264 head pan of gravel

  2. Block  :
  • Exterior : 416 units of block
  • Interior : 437  units of block

Level break down

  •  Exterior wall : 934 units of block
  • Interior wall : 1091 units of block

Roof details

  • Ridge cap : 42'
  • Hip ridge cap : 134'
  • 4x8' roof sheet : 54 counts
  • Down spout : 19
Note that these estimate are  70% accurate.
For more detail about roofing terminology you can check my our my facebook page
Hope you have a nice time here ?
download link for this plan is as below
and
for comment,criticism or suggestion  you can mail me on 247drawing@gmail.com

Monday, 2 May 2016

Three bedroom bungalow


 What is a bungalow

                  A bungalow is small house or cottage usually having a single story. It always contain at least a living area, a room, dinning, kitchen, store(if necessary), Porch( entrance and exits), a toilet ( water closet and shower).It may also have library, foyer, a bar, laundry, studio and even garage provide it is up to one's taste and it is avoidable .
                Also a bungalow is a type of building, originally from Bengal region in South Asia, but now found throughout the world. Across the world, the meaning of the word bungalow varies. Common features of many bungalows include verandas and being low-rise. In Australia, the California bungalow was popular after the First World War. In North America and the United Kingdom a bungalow today is a residential building, normally detached, which is either single-story or has a second story built into a sloping roof, usually with dormer windows (one-and-a-half stories)[a]
              Three bedroom  house plan from history seems to be the most commonest preferred house plan be it bungalow or duplex, the reason for this differ but people always arrive at the same answer, i mean three bedroom bungalow. Some people may decide to have two room down and one room up (duplex) , while some prefer to build all on a ground level (bungalow) which help to reduce cost.
             The term originated in India, deriving from the Gujarati બંગલો baṅgalo, meaning "Bengali" and used elliptically for a "house in the Bengal style".This Asian architectural form and design originated in the countryside of Bengal region in South Asia. Such houses were traditionally small, only one storey and detached, and had a wide veranda. The term was first found in English from 1696, where it was used to describe "bungales or hovells" in India for English sailors of the East India Company. Later it became used for the spacious homes or official lodgings of officials of the British Raj, and was so known in Britain and later America, where it initially had high status and exotic connotations, and began to be used in the late 19th century for large country or suburban houses built in an Arts and Crafts or other Western vernacular style—essentially as large cottages, a term also sometimes used. Later developers began to use the term for smaller houses.[b]
               This particular plan is a three bedroom bungalow plan with two car garage, kitchen, dinning, Main living,a store, verandah, kitchen, two toilet (water closet and shower).
                                                            orthogonal view
www.latesthouseplan.blogspot.com

www.latesthouseplan.blogspot.com

www.latesthouseplan.blogspot.com


STAT

  • Bedroom: three bedroom
  • bathroom: one private and one general toilet
  • Living area: single Main living
  • Dinning : casual
  • Garage:two car
  • Bonus room :none
  • Out door living : verandah and balcony
  • Ceiling height :  9'
  • Width x depth : 52'- 9" x 35'- 6"

Foundation details

  1. Concrete
    • Cement :281/2 bags of cement
    • Sharp sand : 114 head pan of sharp sand
    • Gravel : 229 head pan of gravel

  2. Block  :
  • Exterior : 470 units of block
  • Interior : 425  units of block

Level break down

  •  Exterior wall 1000 units of block
  • Interior wall : 1025 units of block

Roof details

  • Ridge cap : 39'
  • Hip ridge cap : 164'
  • 4x8' roof sheet : 66 counts
  • Down spout : 18
Note that these estimate are +/- 5% accurate.
For more detail about roofing terminology you can check my our my facebook page
Hope you have a nice time here ?
download link for this plan is as below
and
for comment,criticism or suggestion  you can mail me on 247drawing@gmail.com
Reference



Saturday, 23 April 2016

Simple Three bedroom Bungalow

What is a Bungalow?

               A Bungalow is small house or cottage usually having a single story. It always contain at least a living area, a room, dinning, kitchen, store(if necessary), Porch( entrance and exits), a toilet ( water closet and shower).It may also have library, foyer, a bar, laundry, studio and even garage provide it is up to one's taste and it is avoidable .
                Three bedroom house plan from history seems to be the most commonest preferred house plan be it bungalow or duplex, the reason for this differ but people always arrive at the same answer, i mean three bedroom bungalow. Some people may decide to have two room down and one room up (duplex) , while some prefer to build all on a ground level (bungalow) which help to reduce cost.
              This particular plan is a three bedroom plan with a kitchen, dinning, Main living,a store, verandah, kitchen, three toilet (water closet and shower).
              This plan can be said to to be portable because it was designed to fit into 15m by 15m( 50'x 50') and after which their is small portion of land to allow access or walk way and also space for car park.
              Follow this post to the end so as to gain from it.
www.latesthouseplan.blogspot.com


                                                             orthogonal view

www.latesthouseplan.blogspot.com
                                                           area view of the plan
www.latesthouseplan.blogspot.com
                                                      area view of the plan

STAT

  • Bedroom: three bedroom
  • bathroom: two private and one general toilet
  • Living area: single Main living
  • Dinning : casual
  • Garage:none
  • Bonus room :none
  • Out door living : verandah and balcony
  • Ceiling height :  9'
  • Width x depth : 35' x 39' 6"

Foundation details

  1. Concrete
    • Cement : 27 bags of cement
    • Sharp sand : 110 head pan of sharp sand
    • Gravel : 220 head pan of gravel

  2. Block  :
  • Exterior : 397 units of block
  • Interior : 4461/2  units of block

Level break down

  •  Exterior wall : 870 units of block
  • Interior wall : 1100 units of block

Roof details

  • Ridge cap : 29'
  • Hip ridge cap : 106'
  • 4x8' roof sheet : 56 counts
  • Down spout : 11
Note that these estimate are +/- 5% accurate.
For more detail about roofing terminology you can check my our my facebook page @ www.facebook.com/Siksakandco Architectural Designer

Hope you have a nice time here ?
download link for this plan is as below
and

For suggestion, correction or question you can mail us at 247drawing@gmail.com
